Basic Info.
Model NO.
0.20mm-3mm
HS Code
39219090, 39219090
Process
Extrusion
Raw Material
100% Virgin Raw Material
Transport Package
Rolls
Specification
THK: 0.2-3mm
Trademark
MC plastics
Origin
China
Production Capacity
20, 000mts/Year
Product Description
- Product Description
- LLDPE LDPE PVC EVA HDPE Geomembrane/Liners
- Geomembrane is a kind of waterproof material with basic raw material of high molecular polymer Produced by blow molding or extrusion process.
- It is mainly divided into HDPE geomembrane ,LDPE geomembrane, LLDPE Geomembrane, PVC Geomembrane,EVA geomembrance, and all kinds of composite geomembranes.
- TDS
| Items | Test | Requirement | Remark |
| 1 | Surface | Free of any contaminants that impedes its good operation, no obvious defects, no wrinkles, no scratches | |
| 2 | Thickness (mm) | 0.2-3 | |
| 3 | Width (mm) | 1mm-7.5m | |
| 4 | Length(m) | Customize(More than 30m) | |
| 5 | Density | 0.94-0.96 | |
| 6 | Tension strength MD(Mpa) | >8(Type I) >12(TypeII) | |
| 7 | Elongation(%) | >200(Type I) >250(TypeII) | |
| 8 | Shrink in heat treatment(%) | <3(Type I) <2(TypeII) | |
| 9 | Bending low temperature(Degree) | Type I:No crack at-20 II:-25 | |
| 10 | Oxidation induction time (OIT) | 100Minute | |
| 11 | Elongation at break(%) | Max 700 | |
| 12 | Dimensional stability(%) | +/-2 | |
| 13 | Gram/M2 | Customize | |
| 14 | Application | Roof waterproofing, such as industry and civil roof.Underground waterproofing, including reservoir, dam , channel and cellar Tunnel, expressway, bridge , landfill and artifical lake | |
| 15 | Packaging | Rolls, outside with PP bag | |
| 16 | Process | high-grade polyethylene resin by co- extrusion-blown process | |
| 17 | Storage Condition | No special requirements. | |
| 18 | Shelf Life | More than 50 years |
