Basic Info.
Model NO.
geogrid
Classification
Plastic Geogrid
Material
Plastic
Width
1-6m
Length
100m or Customized Length
MOQ
5000sqm
Certificate
ISO9001
Keyword
Geogrid
Mesh Size (mm)
12.7*12.7mm. 25.4*25.4mm
Samples
Free
Name
Factory Price High Strength PP Biaxial Geogrid PLA
Specification
100%virgin
Trademark
Dajin
Origin
Shandong, China
HS Code
39269090
Production Capacity
50000sqm/Day
Product Description
Factory Price High Strength PP Biaxial Geogrid Plastic Soil Stabilization geo grid
PP Polypropylene Plastic Biaxial Geogrid for road highway railway construction reinforcement is the kind of geosynthetic material which is widely used to reinforce retaining walls, as well as
subbases or subsoils below roads or structures.
subbases or subsoils below roads or structures.
Plastic biaxial geogrid is often made from plastic materials which are polypropylene or high-density polyethylene (HDPE) resins through the processes of extruding, sheet forming, punching and stretching. Compared with uniaxial plastic geogrid, biaxial plastic geogrid has high tensile strength and excellent tensile modulus in both longitudinal and transverse direction, so the plastic biaxial geogrid can offer superior stiffness, high strength at low strain, aperture stability and interlock capabilities, maximum bearing capacity and shear resistance for structural reinforcement of paved and unpaved roads. Dajin plastic biaxial geogrid can be used as soil reinforcement below roads,under structures, behind retaining walls, pavement overlays reinforcement, strengthening soft ground of highway, railway, slope protecting projects and airfields, it can also enhance soil structure, prevent soil erosion, increase stability and loading capacity of foundation, prolong the project life.
1.High tension resistance, high plane torsion resistance modulus, good creep resistance and stable chemical nature.
2.High mechanic damage resistance and durability and large friction factor with sandy stone.
3. Improve the bearing capacity of the roadbed and extend the service life of the roadbed.
4. It can decrease 30%-40% of filling thickness for reaching same effect, save cost.
5. Convenient construction, saving effort, shortening construction period and reducing maintenance cost.
6. Strengthen soil slopes to prevent soil erosion.
7. Can replace metal mesh, used in coal mine underground false roof network.
8. Supporting the stability of grass slope mats, greening environment.
2.High mechanic damage resistance and durability and large friction factor with sandy stone.
3. Improve the bearing capacity of the roadbed and extend the service life of the roadbed.
4. It can decrease 30%-40% of filling thickness for reaching same effect, save cost.
5. Convenient construction, saving effort, shortening construction period and reducing maintenance cost.
6. Strengthen soil slopes to prevent soil erosion.
7. Can replace metal mesh, used in coal mine underground false roof network.
8. Supporting the stability of grass slope mats, greening environment.
| Property | TGSG15-15 | TGSG20-20 | TGSG30-30 | TGSG40-40 |
| Tensile strength KN/m | 15 | 20 | 30 | 40 |
| Elongation % | 13 | 13 | 13 | 13 |
| Load at 2% strain KN/m | 5 | 7 | 10.5 | 14 |
| load at 5% strain KN/m | 7 | 14 | 21 | 28 |
The geogrid rolls size can be customized according to your requirement.
2. Reinforcement of permanent bearing road beds of large parking area and dock goods yard.
3. Slope protections and culvert reinforcement of railway and highway.
4. Secondary reinforcement of soil slope after unidirectional tension geotechnical grid reinforcement and further reinforcement of soil slope sp as to avoid soil erosion.
5. Reinforcement of mile and gallery.
Shandong Dajin Geosynthetics Co.,LTD. is located in Jinan City, Shandong, China, which is a comprehensive service provider as well as solution provider integrating design, production and construction.
The products provided by Dajin include geotextile, geomembrane, composite geomembrane warp-knitted geogrid, glass fiber geogrid, plastic geogrid, steel-plastic geogrid, mining geogrid, high-strength mining polyester fiber mesh, geocell and other geosynthetics. Dajin possesses three production bases and a complete QC system, and our product quality, technology and equipment lie in top of the industry. Our goal is to become a world-class company dedicated to providing our customers with comprehensive, reliable and high-quality services and solutio.
With 20 years experience, we could help to save your cost and time!
