Basic Info.
Model NO.
EGA
Grid Size
25.4X25.4mm
Tensile Strength Md
100kn/M
Tensile Strength CD
200kn/M
Max Width
5.85m
Transport Package
Plastic Film
Specification
CE
Trademark
Utek
Origin
China
HS Code
7019
Production Capacity
1000000m2
Product Description
Fiberglass geogrids are knitted of high strength fiberglass yarns. The yarns are coated with a bituminous material which ensures proper adhesion to the asphalt layers.Used to control the cracking of airport runways, taxiways, roads, bridges, jointed concrete carriageways, parking lots, etc.
Excellent heat resistance and minimal shrinkage at high temperature of more than 200° C
Typical Uses:
To increase the fatigue life of bituminous pavements
To control rutting of pavements subjected to high trafficking
Construction of new highways
Maintenance and repair for asphalt pavements
Technical Parameters:
Give us a chance, and we' ll return you with satisfaction.
Excellent heat resistance and minimal shrinkage at high temperature of more than 200° C
Typical Uses:
To increase the fatigue life of bituminous pavements
To control rutting of pavements subjected to high trafficking
Construction of new highways
Maintenance and repair for asphalt pavements
Technical Parameters:
| Specification | EGA25-25 | EGA80-80 | EGA120-120 | EGA400-400 | |
| Breaking strength (kN/m) | Warp | 25 | 80 | 120 | 400 |
| Weft | 25 | 80 | 120 | 400 | |
| Breaking elongation ( % ) | ≤ 3 | ≤ 3 | ≤ 3 | ≤ 3 | |
| Grid size (mm x mm) | 25.4x25.4 / 12.7x12.7 / 50x50 | ||||
| Max. width (m) | 5.85 | 5.85 | 5.85 | 5.85 | |
| Coating | Modified bitumen | Modified bitumen | Modified bitumen | Modified bitumen | |
Give us a chance, and we' ll return you with satisfaction.
