Basic Info.
Model NO.
ADTO precoating galvanized corrugated sheet
Stock
Not Stock
Use
Construction, Building, Electric Industry, etc.
Width
600mm-1580mm
Length
Customer′s Requirement
Tolerance
5%
Coil ID
508mm,610mm
Grade
SPCC,DC01,DC03
Coil Weight
3-5mt, or as Per Customers′ Requests
Color
as Per Customers′ Requests
Zinc Coating
20-275G/M2
MOQ
2 Tons
Gloss (Gardner 60°)
15 Gu to 90gu
Thickness of Organic Coating
20-45micro(as Customer′s Requirement)
Pattern
Flower, Fabric, 3D, Hairline, and Customized
Paint
PE, PVDF, SMP, HDP
Processing Service
Bending, Welding, Decoiling, Cutting, Punching
Transport Package
Standard Export Packing
Specification
according to the product size
Trademark
custom
Origin
China
HS Code
7210701000
Production Capacity
50000000tons/Year
Product Description
| Contents | Prepainted Galvanized-PPGI | Prepainted Galvalume-PPGL |
| BASE METAL | GALVANIZED | GALVALUME / ALUZINC |
| JIS G -3312,ASTM A -755 , | ASTM A 755M, | |
| STANDARDS | EN -10169, IS -14246,G300-G550 | WITH SUBSTRATE ASTM A792 M |
| THICKNESS | 0.12~1.50 mm | 0.12~1.50 mm |
| Width | 700 TO 1580 mm | 700 TO 1580 mm |
| Coil ID | 508 & 610 mm | 508 & 610 mm |
| Coil OD | 1700 mm max | 1700 mm max |
| Coil WT | 3 TO 8 MT | 3 TO 8 MT Max - With ref. to width of coil |
| Hardness | Soft, Medium, Hard | Soft, Medium, Hard |
| YS (Mpa) | 240 -700 | 240 -700 |
| Coating Mass | Z 20-275 (Grams / m2) | AZ 20-150 (Grams / m2) |
| Primers: Epoxy, PU | Primers: Epoxy, PU | |
| Polyester (RMP/PE) | Polyester (RMP/PE) | |
| Paint Systems | Silicon Modified Polyester (SMP) | Silicon Modified Polyester (SMP) |
| Poly Vinyl Di Flouride (PVDF) | Poly Vinyl Di Flouride (PVDF) | |
| Back Coating: Epoxy, Polyester, PU | Back Coating: Epoxy, Polyester, PU | |
| Coating | 20 - 50 Microns | 20 - 50 Microns |
| Thickness | top can 3 coats and back can 2 coats | top can 3 coats and back can 2 coats |
| Colour | As Per RAL Chart/Customer requirements. | As Per RAL Chart/Customer requirements. |
| Surface Finishes | Glossy and Matte | Glossy and Matte |
| Cut to length | 200mm-5000mm | 200mm-5000mm |
| Slits | 30mm and above | 30mm and above |
| Packing | Sea Worthy Export Packaging | Sea Worthy Export Packaging |
ANY PATTERN DESIGN CAN BE CUSTOMIZED
Standard Export Packing:
- 4 eye bands and 4 circumferential bands in steel
- Galvanized metal fluted rings on inner and outer edges
- Galvanized metal and waterproof paper wall protection disk
- Galvanized metal and waterproof paper around circumference and bore protection
1. How can I get a quotation from you ?
You can leave us message, and we will reply every message in time. Or we may talk on line by Trademanager.And you can also find our contact information on contact page.
2.Can I get samples before order ?
Yes, of course. Usually our samples are free.
3. what is your delivery time ?
The time of delivery is usually around 20 days(1*40FT as usual).
We can send out in 2 days, if it has stock.
4.What is your payment terms?
Our usual payment term is 30% deposite, and rest against TT 70% B/L. L/C is also acceptatble.EXW,FOB,CFR,CIF,DDU.
5. How can you garantee what I got will be good ?
We are factory with 100% predelivery inspection which garantee the quality.
And as golden supplier on Made-in-China. which means alibaba will pay your money back in advance if there is any problem with the products.
6 How do you make our business long-term and good relationship?
A:1. We keep good quality and competitive price to ensure our customers benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends with them,?
no matter where they come from.
Please feel free to leave us message if you have any question about us and our products.
