Basic Info.
Model NO.
110g/m2-800g/m2
Transport Package
Woven Bag
Specification
6m*100m or customized
Trademark
DISTINCT
Origin
Yantai, Shandong Province
HS Code
5603949000
Production Capacity
20000 Sqms/Day
Product Description
Function Description:
PET Filament Spunbonded Nonwoven Geotextile is Made by nonwoven needle punched manufacturing process, it has isolation, filtration, drainage, protection and maintenance etc.
Specification:
1)110g/m 2 --800g/m 2
2)1m--8m in roll width, the length as clients' request.
Application:
1)Water conservancy project and hydropower project.
2)Road paving, railway.
3)Airport and Port
4)River bank protection and tunnel
5)Environmental Protection etc.
FAQ
1, Ask: Where is our company located ?
Re: Ling xian County, Dezhou City, Shandong Province. China.
2, Ask: What is the PAYMENT TERMS?
Re: T/T 30% as deposit and balance payed at sight of copy of B/L.
L/C is acceptable, but only IRREVOCABLE 100% at sight.
3, Ask: What is the LEAD TIME?
Re: In one week after receiving the deposit or L/C.
4, Ask: Are FREE SAMPLES available?
Re: Yes. But express delivery costs is to be collected and we will pay it back after confirming the order.
5, Ask: What's your MOQ quantity ?
Re: MOQ is one 20' container , the quantity could be negotiable .
Contact Way:
Manager: Jet Lin
PET Filament Spunbonded Nonwoven Geotextile is Made by nonwoven needle punched manufacturing process, it has isolation, filtration, drainage, protection and maintenance etc.
Specification:
1)110g/m 2 --800g/m 2
2)1m--8m in roll width, the length as clients' request.
Technical specification
No. | Item(g) | 100 | 150 | 200 | 300 | 400 | 500 | 600 | 700 | 800 |
1 | Weight Variation% | -5 | ||||||||
2 | Thickness/mm | 0.8 | 1.2 | 1.6 | 2.2 | 2.8 | 3.4 | 4.2 | 5.5 | 6.8 |
3 | Width Variation% | -0.5 | ||||||||
4 | Breaking Strength /KN/m | 4.5 | 7.5 | 10 | 15 | 20 | 25 | 30 | 40 | 50 |
5 | Elongation at Break/% | 40~80 | ||||||||
6 | CBR Mullen burst Strength / KN | 0.8 | 1.6 | 1.9 | 2.9 | 3.9 | 5.3 | 6.4 | 7.9 | 8.5 |
7 | Sieve Size/mm | 0.05~0.2 | ||||||||
8 | Vertical Permeability Coefficient, cm/s | (1.0~9.9)×(10-1~10-3) | ||||||||
9 | Tear Strength /KN | 0.1 | 0.2 | 0.3 | 0.42 | 0.6 | 0.7 | 0.82 | 1.1 | 1.3 |
Application:
1)Water conservancy project and hydropower project.
2)Road paving, railway.
3)Airport and Port
4)River bank protection and tunnel
5)Environmental Protection etc.
FAQ
1, Ask: Where is our company located ?
Re: Ling xian County, Dezhou City, Shandong Province. China.
2, Ask: What is the PAYMENT TERMS?
Re: T/T 30% as deposit and balance payed at sight of copy of B/L.
L/C is acceptable, but only IRREVOCABLE 100% at sight.
3, Ask: What is the LEAD TIME?
Re: In one week after receiving the deposit or L/C.
4, Ask: Are FREE SAMPLES available?
Re: Yes. But express delivery costs is to be collected and we will pay it back after confirming the order.
5, Ask: What's your MOQ quantity ?
Re: MOQ is one 20' container , the quantity could be negotiable .
Contact Way:
Manager: Jet Lin
